Product Information

Product Type

Product Type

• Ceiling AP

Hardware Specifications

Wi-Fi Radio

Radio design

• Dual-radio
  5 spatial streams
  ● 2.4 GHz: 2 x 2, MU-MIMO
  ● 5 GHz: 3 x 3, MU-MIMO

Maximum wireless data rate

• 5011 Mbps

6 GHz wireless data rate

• No

5 GHz wireless data rate

• 4323 Mbps

2.4 GHz wireless data rate

• 688 Mbps

Antenna

Antenna

• 2.4 GHz: 2 built-in omnidirectional antennas
  5 GHz: 3 built-in omnidirectional antennas

Dimensions and Weight

Product dimensions (W x D x H)

• 208 mm x 208 mm x 40 mm (8.19 in. x 8.19 in. x 1.57 in.) (excluding the mounting bracket)

Color

• White

Weight

• ≤ 0.75 kg (1.65 lbs.) (without packaging materials)

Port Specifications

Number of 10/100/1000BASE-T ports

• 1

Number of 10/100/1000/2500BASE-T ports

• 1

Power Supply and Consumption

Power supply

• ● DC power adapter
  ● PoE/PoE+
  Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.

Local power supply

• Yes, one DC power connector (12 V, 2.5 A)

Dimensions of the DC connector

• Outer diameter: 5.5 mm (0.22 in.)
  Inner diameter: 2.1 mm (0.08 in.)
  Length: 10 mm (0.39 in.)

PoE budget

• No

Maximum power consumption

• 30 W

Environment and Reliability

Operating temperature

• 0°C to 40°C (32°F to 104°F)

Mounting options

• Ceiling/Wall

IP rating

• IP41

Software Specifications

WLAN

Maximum number of associated wireless clients

• 64 (2.4 GHz)
  511 (5 GHz)
  511 (2.4 GHz and 5 GHz enabled)

Maximum number of devices that can be managed

• 300

IP Service

IPv6

• Yes
