Product Information

Product Category

Product Category

• Layer 2

Hardware Specifications

Product Information

Warranty

• 5 years

Port Specifications

Total number of RJ45 ports

• 24

Total number of optical ports

• 4

Number of 1GE combo ports

• No

Number of 1GE SFP ports

• 4

Number of 10GE SFP+ ports

• No

Number of 10/100BASE-T ports

• No

Number of 10/100/1000BASE-T ports

• 24

Number of 10/100/1000/2500BASE-T ports

• No

Number of 100/1000/2.5G/5G/10GBASE-T ports

• No

System Specifications

Forwarding rate

• 41.66 Mpps

Switching capacity

• 56 Gbps(bit/s)

Environment and Reliability

MTBF

• 400,000 hours

Operating temperature

• 0°C to +50°C (32°F to 122°F)

Altitude

• Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
  Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)

Surge protection

• Service port: ±6 kV for common mode
  Power connector: ±6 kV for both common mode and differential mode

Software Specifications

Basic Configurations

PoE watchdog

• No

Interface

Jumbo frame length (MTU)

• 9216 bytes (global configuration mode)

Security

Port isolation

• Yes

Broadcast storm control

• Yes
