Arabirim | • 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+) • AUTO Negotiation • AUTO MDI/MDIX |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Sayısı | Fanless |
Fiziksel Güvenlik Kilidi | Yes |
Harici Güç Kaynağı | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
Paket Yönlendirme Hızı | 0.8928 Mpps |
PoE Portları (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 67 W |
MAC Adres Tablosu | 2K |
Jumbo Frame | 2 KB |
Switching Kapasitesi | 1.2 Gbps |
Boyutlar ( W X D X H ) | 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm) |
Maks. Güç Tüketimi | • 2.52 W (220 V / 50 Hz, no PD connected) • 75.4 W (220 V / 50 Hz, with 67 W PD connected) |
Max Heat Dissipation | • 8.59 BTU/h(no PD connected) • 257.11 BTU/h(with 67 W PD connected) |
