4G Kategori

LTE CAT.4

4G/3G Standartları

FDD-LTE,TDD-LTE,WCDMA,GSM

Working band

Global:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28
TDD-LTE: B38/B40/B41
WCDMA: B1/B5/B8
GSM: 900/1800 MHz
North American:
FDD-LTE: B2/B4//B5/B12/B13/ B14/B66/B71
WCDMA: B2/B4/B5

Maksimum 4G hızı

DL:150Mbps
UL:50Mbps

Wi-Fi Standartları

802.11b/g/n

Wi-Fi Frekansı

2.4GHz

Wi-Fi Hızı

300Mbps

Wi-Fi transmit Power

up to 20dBm

Interface

1 × 10/100 Mbps LAN/WAN Port
1 × 10/100 Mbps LAN Port
1 × 2FF SIM Card Slot
1× Tel Port

Buton

Açma/kapama
WPS/Sıfırlama

Antennas

2 Detachable 4G/3G Antennas
2 Internal Wi-Fi Antennas

LED indicators

Power
Wi-Fi
LAN
Internet
4G/3G Signal strength(3 Bars)

Dimensions（L*W*H）

185*126*60mm

Ağırlık

About 252g

Power supply

Power adapter:Input power AC 100V-240V 50/60Hz
Output power:DC 12V==1A

Yazılım

WAN Tipi

4G/3G or Wired
Support Failover

Ses Hizmeti

VoLTE/CSFB

Wi-Fi İşlevleri

Wi-Fi name & Wi-Fi key
Channel & Bandwidth
Guest Network
Wi-Fi schedule
Wireless repeating
Transmit power
WPS

Wi-Fi security

WPA-PSK, WPA2-PSK, WPA/WPA2

Software features

APP/WEB
DHCP Server
VPN(PPTP Client/L2TP Client/PPTP Server)
Firewall
QOS
Upgrade firmware from local or OTA
IPV4/IPV6
