Arabirim | • 8× 10/100/1000 Mbps RJ45 Ports • AUTO Negotiation • AUTO MDI/MDIX |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Sayısı | Fanless |
Fiziksel Güvenlik Kilidi | Yes |
Harici Güç Kaynağı | External Power Adapter(Output: 53.5VDC / 1.31A) |
Paket Yönlendirme Hızı | 11.904 Mpps |
PoE Portları (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 65 W |
MAC Adres Tablosu | 4K |
Jumbo Frame | 16 KB |
Switching Kapasitesi | 16 Gbps |
Boyutlar ( W X D X H ) | 6.2×4.0×1.0 in (158×101×25 mm) |
Maks. Güç Tüketimi | • 4.59 W (220/50 Hz no PD connected) • 75.75 W (220/50 Hz with 65 W PD connected) |
Max Heat Dissipation | • 15.66 BTU/h (no PD connected) • 258.46 BTU/h (with 65 W PD connected) |
