Arabirim | • 8× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports) • AUTO Negotiation • AUTO MDI/MDIX |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Sayısı | Fanless |
Fiziksel Güvenlik Kilidi | Yes |
Harici Güç Kaynağı | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
Paket Yönlendirme Hızı | 1.1904 Mpps |
PoE Portları (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4 • Power Supply: 66 W |
MAC Adres Tablosu | 2K |
Jumbo Frame | 2 KB |
Switching Kapasitesi | 1.6 Gbps |
Boyutlar ( W X D X H ) | 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm) |
Maks. Güç Tüketimi | 2.3 W (220 V/ 50 Hz. no PD connected) 73 W (220 V/ 50 Hz. with 66 W PD connected) |
Max Heat Dissipation | 7.84 BTU/h(no PD connected) 248.93 BTU/h(with 66 W PD connected) |
