| Arabirim | • 9× 10/100/1000 Mbps RJ45 Ports
• 1× 1000 Mbps Combo SFP/RJ45 Port
• AUTO Negotiation
• AUTO MDI/MDIX |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Sayısı | Fanless |
| Fiziksel Güvenlik Kilidi | Yes |
| Harici Güç Kaynağı | External Power Adapter (Output: 53.5VDC / 2.43A) |
| Paket Yönlendirme Hızı | 14.88 Mpps |
| PoE Portları (RJ45) | • Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8
• Power Supply: 123 W |
| MAC Adres Tablosu | 4K |
| Jumbo Frame | 16 KB |
| Switching Kapasitesi | 20 Gbps |
| Boyutlar ( W X D X H ) | 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Maks. Güç Tüketimi | • 7.93 W (220V / 50Hz with no PD connected)
• 141.40 W (220V / 50Hz with 123 W PD connected) |
| Max Heat Dissipation | • 27.04 BTU/h (220V / 50Hz with no PD connected)
• 482.17 BTU/h (220V / 50Hz with 123 W PD connected) |
